Specifications: – Lead time: Usually in Stock General: – Provided Equipment: User Manual – Number Of Tare Power: 16 W – Number Of Power Module Free Slots: 0 – Number Of Power Module Filled Slots: 0 – Redundant: No – Ups Size: Ws Physical: – Cable Length: 1.22 M – Depth: 39 Cm – Height: 19 Cm – Mounting Support: Floor – Mounting Preference: No Preference – Net Weight: 10.2 Kg – Mounting Mode: Not Rack-mountable – Two Post Mountable: 0 – Usb Compatible: No – Width: 14 Cm Input: – Network Frequency: 50/60 Hz /- 5 Hz Auto-sensing – Plug Standard: Schuko – Input Voltage Limits: 140…300 V 230 V Ac – Number Of Cables: 1 – Input Voltage: 230 V Ac 1 Phase – Cos Phi: 0.56 Output: – Rated Power In W: 900 W – Maximum Configurable Power In W: 900 W – Output Frequency: 50/60 Hz /- 1 Hz Sync To Mains – Ups Type: Line Interactive – Wave Type: Stepped Approximation To A Sinewave – Nb Of Power Socket Outlets: 4 Schuko – Curve Equation: Efficiency – Curve Fixed Loss: 0.0208 – Curve Load Maximum: 100 % – Curve Load Minimum: 3 % – Curve Proportional Loss: 0 – Curve Square Loss: 0.0102 – Curve X-axis Maximum: 100 % – Curve Test Cond Id: Curve Fit Of Data Measured In Accordance With The Energy Star Test Method For Uninterruptible Power Supplies. All Measurements Taken In Normal Mode(s), At Typical Environmental Conditions, With 230v/50hz Electrical Input And Balanced Resistive Load (pf = 1.0) Output. – Curve X-axis Minimum: 0 % – Curve X-axis Title: Load – Curve X-axis Units: Percentage – Curve Y-axis Maximum: 100 % – Curve Y-axis Minimum: 50 % – Curve Y-axis Title: Efficiency – Curve Y-axis Units: Percentage – Full Load Runtime: 00:01:00 900 W – Graph Display: 1 – Half Load Runtime: 00:06:30 450 W – Output Voltage: 230 V Ac 1 Phase – Maximum Configurable Power In Va: 1600 Va – Rated Power In Va: 1600 Va – Transfer Time: 6 Ms Typical : 10 Ms Maximum Conformance: – Product certifications: CE, CB – Standards: EN/IEC 62040-1 – EN/IEC 62040-2: CE – Equipment protection policy: Lifetime : 50000 euros Environmental: – ambient air temperature for operation: 0…40 °C – relative humidity: 0…95 % non-condensing – operating altitude: 0…3000 m – ambient air temperature for storage: -15…40 °C – Storage altitude: 0…3000 m – Acoustic level: 40 dBA – Show note OP temperature: No – IP degree of protection: IP20 Batteries & Runtime: – Battery Type: Lead-acid Battery – Number Of Battery Filled Slots: 0 – Number Of Battery Free Slots: 0 – Battery Recharge Time: 8 H – Liquid Value: 0 – Battery Voltage: 12 V – Battery Curve: C – Battery Power In Vah: 124 Vah Runtime – Battery Life: 1…2 Year(s) – Extended Runtime: 0 Communications & Management – Control panel: LED Status display with on line : on battery – Alarm: Alarm when on battery : distinctive low battery alarm Surge Protection and Filtering: – Surge energy rate: 273 J Packing Units: – Package 1 Weight: 11.2 kg Category: Computer & accessories
