DJI RSC 2 General Dimensions Folded: 260×210×75 mm (including the handle) Unfolded: 400×185×175 mm (including the handle and without the Extended Grip/Tripod) Weight Gimbal: Approx. 1216 g (including the battery and excluding Quick-Release Plate) Quick-Release Plate (Upper/Lower) Approx. 102 g Extended Grip/Tripod (Metal): Approx. 226 g Extended Grip/Tripod (Plastic): Approx. 160 g Peripheral Intelligent Battery Model: RB2-3400mAh -7.2 V Type: 18650 2S Capacity: 3400mAh Energy: 24.48 Wh Max Battery Life: 14 hours Charging time: Approx. 2 hours to fully charge with 18W fast charging (PD and QC 2.0 fast charging protocols are supported) Charging temperature: 5° to 40° C (41° to 104° F) Main Connections Bluetooth 5.0; USB-C Accessory Connections NATO port M4 Mounting Hole 1/4”-20 Mounting Hole Cold Shoe Mount Video Transmission/Follow Focus Motor Port (USB-C) RSS Camera Control Port (USB-C) Follow Focus Motor Port (USB-C) Working Performance Tested Payload ≤3.0 kg (Handheld) Angular Vibration Range ±0.02° Maximum Controlled Rotation Speed Pan: 360°/s Roll: 360°/s Tilt: 360°/s Mechanical Endpoint Range Pan: 360° continuous rotation Roll: -240° to 95° Tilt: -112° to 214° Intelligent Features ActiveTrack 3.0; Force Mobile; Panorama; Timelapse; Track; 3D Roll 360; FPV Mode; SuperSmooth; Portrait mode; Gaming Controller Mechanical and Electrical Characteristics Operating Temperature -20° to 45° C (-4° to 113° F) Weight Gimbal: Approx. 1216 g (including the battery and excluding Quick-Release Plate) Quick-Release Plate (Upper/Lower) Approx. 102 g Extended Grip/Tripod (Metal): Approx. 226 g Extended Grip/Tripod (Plastic): Approx. 160 g Axis Locks Yes Gimbal Dimensions Folded: 260×210×75 mm (including the handle) Unfolded: 400×185×175 mm (including the handle and without the Extended Grip/Tripod) Quick-Release Plate (Arca-Swiss/Manfrotto) Yes Carbon Fiber Construction No Foldable Design Yes Built-in Screen 1” OLED Screen Removable Battery Handle No Fine-Tune Balancing Knob No Dual-Layer Camera Plate System Yes RavenEye Support Full Support
