S Specifications in detail Optical Features / Specifications Image Size – 35mm Film Equivalent Focal Length (mm) – Angle of View (Horzntl, Vertl, Diagnl) 74° – 19°20′, 53° – 13°, 84° – 23°20′ Lens Construction (Elements/Groups) 17/12 Number of Diaphragm Blades 10 Minimum Aperture 22 Closest Focusing Distance (m) 0.45 Maximum Magnification (x) 0.24 (at 105mm) Distance Information Yes Image Stabilizer OIS1 Yes, 4-stop AF Actuator Ring USM2 Accessories Lens Cap E-77II Lens Hood EW-83M Lens Case/Pouch LP1219 Rear End Cap Lens Dust Cap E Magnification with Extension Tube EF12 II 0.6 – 0.41 Magnification with Extension Tube EF25 II 0.61 at Tele (Not compatible at Wide) Extender Compatibility Not Compatible Other Accessories Close up lens 500D, Gelatin Filter Holder IV Physical Specifications Filter Diameter (mm) 77 Max. Diameter x Length (mm)3 83.5 x 118 Weight (g) 795 Tested under CIPA standards Full time Manual focus Lens dimensions when in retracted state Category: Camera
